    so i am looking to put a t3 in place of the 14b in my car in hopes of actually passing the 200whp mark on the dyno. here are pics of the manifold i made to pass this goal.
    I managed to buy an old manifold that my friend bought for his focus for the price of a full tank of gas then i cut it and welded it to a fitting b-series exhaust manifold flange. all i need to do is mock it up for turbo fitting.
    [​IMG]

    you can see where i had to cut the manifold in order to bring the runners closer together. I am hoping that this manifold will flow many times better than the DSM manifold i cut apart before. it should fit better since i am using a honda flange ratehr than one i made myself, so less worries that it will spit out a gasket.
    [​IMG]

    Last edited: Jan 5, 2007
    1 person likes this.
  2. Estorvito

    Estorvito Soy Boricua

    Messages:
    2,036
    Likes Received:
    4
    Joined:
    Oct 17, 2004
    Location:
    Orlando FL
    looks good. Hope it works.

    Good job/luck

  3. jimboburgess

    jimboburgess Go fast, Go Cheap

    Messages:
    1,341
    Likes Received:
    14
    Joined:
    May 7, 2005
    Location:
    nyc
    your sig says it perfectly, how do you like my welds, they could be better, all i made sure was that there were no holes, the material was fairly thin.

  4. Estorvito

    Estorvito Soy Boricua

    Messages:
    2,036
    Likes Received:
    4
    Joined:
    Oct 17, 2004
    Location:
    Orlando FL
    yeah the welds look like shit...lol
    But as long as there are no leaks you should be fine....

    I made a manifold once, but kept craking, so I went and ordered one from afi for 600 shipped.
    what turbo are you running?

    Last edited: Jan 11, 2007
  5. jimboburgess

    jimboburgess Go fast, Go Cheap

    Messages:
    1,341
    Likes Received:
    14
    Joined:
    May 7, 2005
    Location:
    nyc
    nissan t3 .60 intake .63 hot
    i only ever get the chance to weld on my own stuff and i get impatient, i guess it's good i only weld my own stuff.

  6. Estorvito

    Estorvito Soy Boricua

    Messages:
    2,036
    Likes Received:
    4
    Joined:
    Oct 17, 2004
    Location:
    Orlando FL
    lmao... thats wuzuuppp..
    well. good luck with your project...

  7. 801CRX

    801CRX Got Rice?

    Messages:
    1,347
    Likes Received:
    12
    Joined:
    Dec 2, 2006
    Location:
    UTAH
    You should checkout homemadeturbo.com they have got plenty of home built turbo projects.

  8. SlushboxTeggy

    SlushboxTeggy It's only stupid if it doesn't work VIP

    Messages:
    9,392
    Likes Received:
    245
    Joined:
    Sep 14, 2004
    Location:
    New Jersey
    I love your del sol and every time I see it it makes me want to sell the teg and get one. So stop posting, haha.

  9. hcivic.com

    hcivic.com Senior Member

    Messages:
    4,571
    Likes Received:
    2
    Joined:
    Jan 7, 2003
    Location:
    Calgary Alberta canada
    what did you usea mig with what wire? you cannot weld cast with a mig. Its gonning to crack at the flage

  10. jimboburgess

    jimboburgess Go fast, Go Cheap

    Messages:
    1,341
    Likes Received:
    14
    Joined:
    May 7, 2005
    Location:
    nyc
    That is one of my main resources i use. it came in very handy for installing my dsm injectors.
    it may be halfassed, but it's turbo charged and you know it when you drive it. I love it too. I am happy i have a second car to use as a dd while i can do thing like a larger turbo install. downtime is no problem now.
    I don't think there will be too much to worry about with cracking, this material is thinner than the heavy cast manifold i currently am using, but it places around the flange and when i weld the T3 flange on i take extra care to make the welds solid and the flow is uninterupted, by taking my time with a grinder and rewelding when necessary smooth changes should prevent hot spots on the manifold and therefore i can hopefully avoid any cracking issues. The piping is ford racing so i trust it be well built.

  11. turbo sol

    turbo sol I need some ligaments!!!

    Messages:
    791
    Likes Received:
    4
    Joined:
    Oct 6, 2006
    Location:
    laurel, montucky (ten minutes out of billings)
    you should weld up some support brackets to it to keep it from possibly cracking under the weght...

  12. Turbo&Auto

    Turbo&Auto Nick Go FAST!!

    Messages:
    3,269
    Likes Received:
    29
    Joined:
    Jan 9, 2006
    Location:
    East Burg, PA!
    Doesnt look too too bad. You're going to need to bring the turbo mounting flange WAY down to fit the turbo.

  13. jimboburgess

    jimboburgess Go fast, Go Cheap

    Messages:
    1,341
    Likes Received:
    14
    Joined:
    May 7, 2005
    Location:
    nyc
    ideas on support braces? just one per runner?
    i still need to weld the t3 flange on i was wait to get everything fit til i could put it on the car
    cause i am fabbing the downpipe at the same time.

  14. TunerToys

    TunerToys Junior Member

    Messages:
    22
    Likes Received:
    0
    Joined:
    Jan 28, 2006
    At least a couple from the head flange to the turbo flange. More is better. You don't want to take any chances on something cracking and dropping your turbo on the ground. With the thinwall materials, the heast cycling of normal operation is going to cause cracking at some point, just keep an eye on it, and weld them back up when they occur.

    Craig

  15. jimboburgess

    jimboburgess Go fast, Go Cheap

    Messages:
    1,341
    Likes Received:
    14
    Joined:
    May 7, 2005
    Location:
    nyc
    more isn't always better but i'll post it up proper.

  16. bitchasscracker

    bitchasscracker Banned

    Messages:
    61
    Likes Received:
    1
    Joined:
    Jun 25, 2006
    Location:
    sioux city iowa
  17. jimboburgess

    jimboburgess Go fast, Go Cheap

    Messages:
    1,341
    Likes Received:
    14
    Joined:
    May 7, 2005
    Location:
    nyc
    thanks, (also sarcasm) it waas rough to weld not my best work, that's what i get for never taking classes.
    anyway here's a pic of the manifold on my car
    [​IMG]
    and here's a pic of the turbo that's going in place of my old 14b which i'll miss.
    [​IMG]
    finally the old turbo for size comparo
    [​IMG]

  18. jimboburgess

    jimboburgess Go fast, Go Cheap

    Messages:
    1,341
    Likes Received:
    14
    Joined:
    May 7, 2005
    Location:
    nyc
    i decided against bracing, the manifold was originally ford racing so it should be plenty sturdy
    [​IMG]
    [​IMG]
    finished, i had to angle everything for two reasons
    so it would fit
    for the sweet jdm look

    Last edited: Jan 16, 2007
