integra clutch cable..

Discussion in 'HYBRID -> ED-EF / DA' started by 14 sec. windstar, Jul 20, 2007.

  1. 14 sec. windstar

    14 sec. windstar New Member

    Messages:
    110
    Likes Received:
    0
    Joined:
    Mar 3, 2007
    ok im swaping a b16a into a 90 ls and i cant seem to get the clutch cable right... its also was an automatic so i pit in my padel assmebly and drill a hole for my clutch cable and its not work when i conect it all it just hold my clutch all the way up... ive tried ajusting but its still not working right help?

  2. brian11to1

    brian11to1 Senior Member

    Messages:
    9,203
    Likes Received:
    21
    Joined:
    Jan 9, 2003
    did you drill the hole big enough for the metal jacket on the clutch cable to fit through....

  3. freak86

    freak86 New Member

    Messages:
    287
    Likes Received:
    0
    Joined:
    Jul 28, 2006
    Location:
    Southwest Michigan
    so, there's no slack in the cable? can you still lift the bar on the trans. by hand? it should be right at the point where you can't lift it by hand, and there shouldn't be any slack in the cable. the pedal should be resting in it's normal position.
    what cable are you using?

  4. 14 sec. windstar

    14 sec. windstar New Member

    Messages:
    110
    Likes Received:
    0
    Joined:
    Mar 3, 2007
    ok my clutch bar moves about 3-4 inches so when i hook my clutch cable to my pedal assembly and to the bar theres like no slack the bars in the up position...is this right? and my using a 92 integra gs cable

  5. smokey345

    smokey345 SwAp CrAzY

    Messages:
    47
    Likes Received:
    0
    Joined:
    Mar 17, 2007
    Yes that should be right. There should be no slack number one on that bar you can pull up with nyour hand like said before. Where the clutch cable goes into the firewall it should have locked in place and the wire from there inside the firewall should be connected to the clutch pedal. Then after that is all done adjust the pedal using your hand right near the bar and screwing that plastic round thing down until you can't screw it with your hands anymore or until no slack is felt in the bar. Then try your cluctch and if that still doesen't work then maybe the hole you drilled is messing up the pressure you are suppose to place on the clutch.

  6. 14 sec. windstar

    14 sec. windstar New Member

    Messages:
    110
    Likes Received:
    0
    Joined:
    Mar 3, 2007
    ok so let me get this right once everything is connected... my bar should be all the way up and the cable hella tight? without the clutch pedal engaged

  7. freak86

    freak86 New Member

    Messages:
    287
    Likes Received:
    0
    Joined:
    Jul 28, 2006
    Location:
    Southwest Michigan
    exactly....well, it isn't all the way up. it's just up as far as you can lift it by hand or whatever. when you depress the pedal, it should go up more, but that's a different story.
    *edit* well, technically, there should be SOME slack. like, an eighth of an inch or something. someone put it in one of my posts about the clutch cable for my swap a while back. let me know if you want me to dig :) honestly, just leave like a tiny tiny amount of slack in it. i don't know why it's there tbh.

    Last edited: Jul 25, 2007
  8. 14 sec. windstar

    14 sec. windstar New Member

    Messages:
    110
    Likes Received:
    0
    Joined:
    Mar 3, 2007
    aight thanks man i thought i had it all wrong you a huge help

  9. freak86

    freak86 New Member

    Messages:
    287
    Likes Received:
    0
    Joined:
    Jul 28, 2006
    Location:
    Southwest Michigan
    your welcome. let us know if you get everything fixed

  10. 14 sec. windstar

    14 sec. windstar New Member

    Messages:
    110
    Likes Received:
    0
    Joined:
    Mar 3, 2007
    ok well thought i had it figured out but the clutch cable is still way to tight to connect everything.... do i have to change my bracket where it holds my clutch cable adjustment to a b18 one?? or is the b16 bracket the same? cuz i know im doing something wrong here

  11. freak86

    freak86 New Member

    Messages:
    287
    Likes Received:
    0
    Joined:
    Jul 28, 2006
    Location:
    Southwest Michigan
    can you post some pics of the situation?
    also, does it look like you can get it in if you can take the bracket off, put the cable in it, then put the bracket back on?
    and did you loosen the adjuster?
    what kind of car exactly do you have? more info needed.
    this is the pic someone gave me for my b16a to 88crxsi swap. hope this helps.

    [​IMG]

    Last edited: Jul 26, 2007
  12. 14 sec. windstar

    14 sec. windstar New Member

    Messages:
    110
    Likes Received:
    0
    Joined:
    Mar 3, 2007
    um idk how to get pics on here but ive tried taking the bracket offf then putting it back on its like an inch from going on and the adjustment srew it loosened all the way and i have a 1990 acura integra automatic that i put a full b16a with b16a tranny i used a 1993 integra pedal assembly and 1993 clutch cable.... i can either get the cable connected to the pedal and then now have enought room to connect the rest or the other way around... idk what im doing wrong....its the only thing left on my swap..... ive spent a good 10 hours trying to get it to work.... not happening

  13. 14 sec. windstar

    14 sec. windstar New Member

    Messages:
    110
    Likes Received:
    0
    Joined:
    Mar 3, 2007
    so the problem is now..... its working (i think) but that little rubber peice that hold the clutch cable into the fire wall.... it popped through my hole... but it seems to work tho... any ideas??? and i have pic.. photobucket?

  14. freak86

    freak86 New Member

    Messages:
    287
    Likes Received:
    0
    Joined:
    Jul 28, 2006
    Location:
    Southwest Michigan
    i was gonna say i didn't think the 93 cable would work. but..... if it's working, then nevermind that.
    don't know what to tell you about the firewall peice/grommet/thing.if it won't stay, could you epoxy it or something? somehow attatch it?

  15. 14 sec. windstar

    14 sec. windstar New Member

    Messages:
    110
    Likes Received:
    0
    Joined:
    Mar 3, 2007
    ok well its not goinmg to stay like it looks like my clutch is going to have to work the way it is bcus its like an inch to short for some reason and now with that peice through the firewall it looks like it might work just becuase of that check it out <a href="Image hosting, free photo sharing & video sharing at Photobucket" target="_blank"><img src="http://i42.photobucket.com/albums/e307/pimpinsmythe69/untitled.jpg" border="0" alt="Photo Sharing and Video Hosting at Photobucket"></a><a href="Image hosting, free photo sharing & video sharing at Photobucket" target="_blank"><img src="http://i42.photobucket.com/albums/e307/pimpinsmythe69/2.jpg" border="0" alt="Photo Sharing and Video Hosting at Photobucket"></a><a href="Image hosting, free photo sharing & video sharing at Photobucket" target="_blank"><img src="http://i42.photobucket.com/albums/e307/pimpinsmythe69/1.jpg" border="0" alt="Photo Sharing and Video Hosting at Photobucket"></a>

  16. 14 sec. windstar

    14 sec. windstar New Member

    Messages:
    110
    Likes Received:
    0
    Joined:
    Mar 3, 2007
  17. 14 sec. windstar

    14 sec. windstar New Member

    Messages:
    110
    Likes Received:
    0
    Joined:
    Mar 3, 2007
  18. freak86

    freak86 New Member

    Messages:
    287
    Likes Received:
    0
    Joined:
    Jul 28, 2006
    Location:
    Southwest Michigan
    maybe get a peice of metal, drill a hole of the correct size in it, and either weld/epoxy/something it to the firewall over the other hole. maybe that would solve that problem. it's hard to see one of the other pics, but it looks like you have the cable in the bracket correctly. i'm going to assume that you have the ball at the end in correctly. so, it looks like the only thing that's not right is at the firewall. if when you get that fixed, it's still too long, then i would say it's the wrong year cable.
    *edit* you said it was a automatic? did you drill the hole for the cable?

    Last edited: Jul 29, 2007
  19. 14 sec. windstar

    14 sec. windstar New Member

    Messages:
    110
    Likes Received:
    0
    Joined:
    Mar 3, 2007
    haha! i fixed it... the guy i got this motor from i took like everything off the car i could then put it in a huge bag.... well there was a clutch cable it there... its work perfect haha

  20. freak86

    freak86 New Member

    Messages:
    287
    Likes Received:
    0
    Joined:
    Jul 28, 2006
    Location:
    Southwest Michigan
    cool. glad to know you got it working. have fun;)
