Please help me out i got this throwing codes

Discussion in 'HYBRID -> ED-EF / DA' started by D16a6EF, Sep 25, 2007.

  1. D16a6EF

    D16a6EF New Member

    Messages:
    50
    Likes Received:
    0
    Joined:
    Jul 23, 2007
    Location:
    Toms River NJ
  2. 91si

    91si New Member

    Messages:
    108
    Likes Received:
    0
    Joined:
    May 26, 2007
    Thats a code 10/ fast blink means (1) and long blink means (10) you have 10 fast blinks, so code 10. which is...[SIZE=-2]IAT Sensor (Intake Air Temperature)[/SIZE]
    [SIZE=-2]defective circuit or unplugged / defective sensor[/SIZE]

  3. D16a6EF

    D16a6EF New Member

    Messages:
    50
    Likes Received:
    0
    Joined:
    Jul 23, 2007
    Location:
    Toms River NJ
    what does it looks like and show me where its located

  4. D16a6EF

    D16a6EF New Member

    Messages:
    50
    Likes Received:
    0
    Joined:
    Jul 23, 2007
    Location:
    Toms River NJ
    and what color the wires is? i have 2 wires is unplugged Green w/ whi stripe, red w/ whi stripes ...other 1 is Blue w/ yel stripe, Blk w/ yel stripe on D16A6 Si

  5. 91si

    91si New Member

    Messages:
    108
    Likes Received:
    0
    Joined:
    May 26, 2007
    Im sure its located on the intake manifold, should be a white sensor.
    Green with white stripe is sensor ground.
    The red with white stripe is sensor power, those would be the wires that goes to the IAT sensor.

  6. D16a6EF

    D16a6EF New Member

    Messages:
    50
    Likes Received:
    0
    Joined:
    Jul 23, 2007
    Location:
    Toms River NJ
    yeah i notice that and i put a wrong plugs lol im such noob haha, But what am i gonna do w/ the other connectors that r blu/yelstripe, blk/yel stripe? and what those are for?

  7. 91si

    91si New Member

    Messages:
    108
    Likes Received:
    0
    Joined:
    May 26, 2007
    Blue/YellowEACV (Coil)
    [FONT=Verdana,Arial,Helvetica,sans-serif][/FONT]
    [FONT=Verdana,Arial,Helvetica,sans-serif][/FONT][FONT=Verdana,Arial,Helvetica,sans-serif]-Electronic Air Control Valve (EACV) wires need to be extended, the EACV is a rectangular box on the back of the intake manifold, it has 2 wires going to it, solder and heatshrink.

    [/FONT]
    [​IMG]

    Yellow/Black 1Main Relay/Injector Resistor Box
    Its like a little silver metal square thing, usallu mounted up by the shocks, check to see if those wires arent connected.
    Heres a pic.[​IMG]

  8. 91si

    91si New Member

    Messages:
    108
    Likes Received:
    0
    Joined:
    May 26, 2007
    Thats all from searchig, try it out. Thats the best i can do.
    Im A NOOB 2!

  9. TurboMirage

    TurboMirage YEEAAAHHH VIP

    Messages:
    24,577
    Likes Received:
    696
    Joined:
    May 20, 2003
    Location:
    Central, MA
    i told him it was the IAT :p
