    I read on Nasioc that you pick up a few HP by tapering the TB out to a knifed edge. Does make sense. The TMIC is directly connected to the TB, so airflow is coming out and then hitting a .25" thick wall. The stock TB also has a lil lip just before the throttle plate too.

    So I started by removing the lil lip and tapering the whole TB. Then polished it up nice and re installed. I noticed some nice off boost throttle response pickup as well as a lil better top end.

    I got bored at work and had a thought....What if I mill that center arm down?? This would make more room for airflow without actually enlarging the center bore of the TB further. This is the results:

    [​IMG]

    [​IMG]

    [​IMG]

    [​IMG]

    [​IMG]

    [​IMG]

    It took the results of the 1st step and just enhanced them even further! The top end is incredible now. I wish I had access to a AWD dyno so I could put some real numbers to this but my g/revs went up when I logged. Before I had a peak of 230 G/rev from 5800 to 7000. Now Im pulling 233-235 from 6K -7200. Im happy with the results :)

    1 person likes this.
  2. eg6sir

    eg6sir Supa Mod Moderator VIP

    Messages:
    21,703
    Likes Received:
    321
    Joined:
    Aug 17, 2005
    Location:
    661 BK CA
    wow, nice work..

  3. TurboMirage

    TurboMirage YEEAAAHHH VIP

    Messages:
    24,577
    Likes Received:
    696
    Joined:
    May 20, 2003
    Location:
    Central, MA
  4. totalburnout

    totalburnout Well-Known Member VIP

    Messages:
    7,068
    Likes Received:
    126
    Joined:
    Oct 22, 2002
    Location:
    NJ
    Nice work.

    Next PNP job; intake manifold. Remove or hone the tumbler gas valves (TGVs). Then throw on a new turbo inlet hose from ebay or the nasioc classifieds.

    I'm sure thats a real nice car you have, especially with it being a few hundred pounds lighter than a WRX and having your constant tuning and tweaking abilities to fine tune.

  5. Turbo&Auto

    Turbo&Auto Nick Go FAST!!

    Messages:
    3,269
    Likes Received:
    29
    Joined:
    Jan 9, 2006
    Location:
    East Burg, PA!
    I just purchased a 20G the other day. Went with the Td06 20g with a 7cm exhaust housing. Hoping to hit full spool around 4K.

    Also picked up DW 750's, APS 65mm CAI, BPM inlet. I plan on removing the Intake Manifold and doing the TGV delete and PNP'ing them as well :)

  6. D15Beater

    D15Beater HNFTuning

    Messages:
    551
    Likes Received:
    8
    Joined:
    Jun 8, 2007
    Location:
    Concord N.C.
    I taper mine out from the plate to the end some too but i do it by hand....drill and several steps with different stones, sanding wheels, polishing wheels, etc,etc....
