Vacuum diagram

Discussion in 'HYBRID -> EG-EK / DC' started by ekh22, Jul 8, 2013.

  1. ekh22

    ekh22 New Member

    Messages:
    28
    Likes Received:
    0
    Joined:
    Jun 6, 2013
    Hey I was wondering if theirs anybody out there with the vacuum diagram of a 96 civic dx with a h22a swap. As in like a picture of how yours is setup. Just asking no "just search" bashing.

  2. Matts96HB

    Matts96HB . Moderator VIP

    Messages:
    6,483
    Likes Received:
    390
    Joined:
    Apr 16, 2006
    I don't have an H22 swapped car, nor have I ever owned one, but you can easily figure this out with a stock schematic from an H22 (or H23, because they are apparently the same.)

    Found this for you, should be a good place to start:
    [​IMG]

    Also, this may be of some help. It's a little small but it is the only one I could find:
    [​IMG]
