    I've already tucked the drivers side of my bay, now I want to do the passanger side.

    I have a complete 5 speed D16Y7 harness OBD2 harness and OBD0 ECU plugs. Will that harness be easy to convert to OBD1 and VTEC? I would keep my OBD0 to OBD1 conversion harness and just solder the OBD0 plugs onto the OBD2 harness.

    Where could I hide the fuse box? In the glove box?

  2. GlassHeadlights

    GlassHeadlights West West Yall

    Messages:
    4,066
    Likes Received:
    71
    Joined:
    Oct 24, 2007
    Location:
    Calgary, AB
    Came up with some issues. I'm missing some plugs, forgot I cut them lol, and quite a few differences. But I had to expect that being OBD2.

    [​IMG]
    [​IMG]

    Have to put on a tempature sensor, get rid of the extra o2 wires and the extra mystery plug.

    [​IMG]

    Dizzy has one plug vs. 2 plugs and 1 more wire on my CRX dizzy.

    [​IMG]

    Big, random plugs.

    [​IMG]

    Alternator plug is different and has 1 less wire than my CRX alt plug.

    [​IMG]

    Unknown plug. Maybe TPS?

    [​IMG]

    Have to change the injector plugs.

    [​IMG]

    Have to put on the MAP plug and some more unknown plugs.

    [​IMG]

  3. Ethan

    Ethan Well-Known Member

    Messages:
    2,945
    Likes Received:
    98
    Joined:
    Jun 30, 2008
    Rywire - Online Store... lol

    you said something about a wire tuck... whats all this shit?
    are you trying to hide the engine harness as much as you can too?

  4. GlassHeadlights

    GlassHeadlights West West Yall

    Messages:
    4,066
    Likes Received:
    71
    Joined:
    Oct 24, 2007
    Location:
    Calgary, AB
    Exactly.

    Fail on my part because I haven't searched yet...going to try and swap over the ECU plugs now. A diagram would be nice. **wink**wink**

  5. GlassHeadlights

    GlassHeadlights West West Yall

    Messages:
    4,066
    Likes Received:
    71
    Joined:
    Oct 24, 2007
    Location:
    Calgary, AB
    Nvm...got it.
    [​IMG]
    [​IMG]
    [​IMG]

    Last edited: Mar 2, 2010
  6. Taco15

    Taco15 I wear stretchy pants VIP

    Messages:
    6,998
    Likes Received:
    203
    Joined:
    Jan 11, 2005
    Location:
    Tallahassee Fl
    WOW.

    you and i are now in the same boat with the wiring.
    I've got the same harness and plan to clean it up and use it as my OBD1 harness to replace the existing tuck in the CRX.

    definitly gonna be keeping an eye out.... :0

  7. Taco15

    Taco15 I wear stretchy pants VIP

    Messages:
    6,998
    Likes Received:
    203
    Joined:
    Jan 11, 2005
    Location:
    Tallahassee Fl
  8. makewheelies304

    makewheelies304 New Member

    Messages:
    324
    Likes Received:
    3
    Joined:
    Jul 10, 2008
    Location:
    ohio
    thats a hell of a write up right there!!

  9. Taco15

    Taco15 I wear stretchy pants VIP

    Messages:
    6,998
    Likes Received:
    203
    Joined:
    Jan 11, 2005
    Location:
    Tallahassee Fl
    soooo how is it going?

    I messed with my harness too and am a little stuck since I have a feeling I have an obd2b harness.
    My alternator plugs look different

  10. GlassHeadlights

    GlassHeadlights West West Yall

    Messages:
    4,066
    Likes Received:
    71
    Joined:
    Oct 24, 2007
    Location:
    Calgary, AB
    I did my B16 swap and gave up on this harness lol. It was for my old swap.

    I think it should be possible to use the OBDII alternator. Just re-wire it to match the colors. My stock CRX harness has 4 dizzy wires and my B16 alt had 3 wires but it will worked. I just cut off the odd wire.

  11. Taco15

    Taco15 I wear stretchy pants VIP

    Messages:
    6,998
    Likes Received:
    203
    Joined:
    Jan 11, 2005
    Location:
    Tallahassee Fl
    darn.
    Well the alternator is easy. I have to swap out plugs anyway since I HAVE an obd1 alternator. everything else on the motor is OBD2.

    welp, back to the research.....

  12. jusplayn85

    jusplayn85 New Member

    Messages:
    5
    Likes Received:
    0
    Joined:
    May 17, 2011
    On our crx we ran the wires through the fenders for the headlights, horns, etc... mouted the everything to do with vacuum in the p/s fender and ran the engine wires through the grommet towards the middle of the engine bay. Mouted the fuse box right above the ecu under the dash. Although it may be different for you as we removed the heater box

  13. GlassHeadlights

    GlassHeadlights West West Yall

    Messages:
    4,066
    Likes Received:
    71
    Joined:
    Oct 24, 2007
    Location:
    Calgary, AB
    Yeah I did pretty much exactly the same. Pics are in my thread. \/ \/
