anyone know which way this thing faces? (pic)

Discussion in 'General Tech and Maintenance' started by Boomer27, Nov 13, 2006.

  1. Boomer27

    Boomer27 New Member

    Messages:
    6
    Likes Received:
    0
    Joined:
    Nov 8, 2006
    i was in the process of putting my motor back together and i got to the crankshaft pulley install and this washer looking type thing has me confused...i don't know which way it faces, what i mean is that is has a tapered/beveled side with rasises in the outer lip and dips in the other, i took some pics...
    beveled side

    [​IMG]

    other side
    [​IMG]

  2. TurboMirage

    TurboMirage YEEAAAHHH VIP

    Messages:
    24,580
    Likes Received:
    696
    Joined:
    May 20, 2003
    Location:
    Central, MA
    think about it...

    the side with all the dirty/wear shit faces the belt.

  3. Boomer27

    Boomer27 New Member

    Messages:
    6
    Likes Received:
    0
    Joined:
    Nov 8, 2006
    ah, yes, that makes sense

    thanks

  4. LateApex31

    LateApex31 New Member

    Messages:
    91
    Likes Received:
    1
    Joined:
    Aug 26, 2006
    Think about it some more after you look at it from the edge. You will see that the washer is conical, and that the big end of the cone faces away from the belt.

  5. TurboMirage

    TurboMirage YEEAAAHHH VIP

    Messages:
    24,580
    Likes Received:
    696
    Joined:
    May 20, 2003
    Location:
    Central, MA
    yes :)

    if you put them on each side of the cam gear, it forms a "track" for the belt to ride in.

    IIRC from the 1g crx that there was one on each side.

  6. Boomer27

    Boomer27 New Member

    Messages:
    6
    Likes Received:
    0
    Joined:
    Nov 8, 2006
    yea, theres one behind the timing belt drive gear that faces the oppisite way the front ones does

  7. TurboMirage

    TurboMirage YEEAAAHHH VIP

    Messages:
    24,580
    Likes Received:
    696
    Joined:
    May 20, 2003
    Location:
    Central, MA
    and there you have it :)
