    Hey guys... here is my engine build... * Updated Pics... 11/2/2010

    H22A1 - OBD1

    Building the motor for a turbo set up... Pictures of the tear down and now the new parts... I will post the engine due to its in the shop and I get it back soon with the new sleeves in it :)

    The engine will be sporting Darton sleaves, SCAT conecting rods, JE pistons, ACL barrings and King engine barrings, The head will have Brain Crower Stage 2 cams with the Brian Crower retaining kit and valves. The cam gears are AEM Tru Cam gears. Also got a Aeromotive a1000 fuel in tank pump to feed the AEM fuel rail with RC 1000 injectors.... We have gone with a turbonetics t3/t4 hybrid for this set up, we have also decided to go with an HKS tital blow off valve... im sure im missing some parts... but here is the parts that have come in... more parts to come :).... oh dyno shop is hopping to put out 500 HP at the crank ;)
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]

    Last edited: Nov 2, 2010
  2. GlassHeadlights

    GlassHeadlights West West Yall

    Messages:
    4,066
    Likes Received:
    71
    Joined:
    Oct 24, 2007
    Location:
    Calgary, AB
    Cooooollllllll!

    How much power are you shooting for?

  3. reikoshea

    reikoshea HS Troll...And Mod Moderator VIP

    Messages:
    12,633
    Likes Received:
    193
    Joined:
    Apr 27, 2005
    Location:
    San Antonio, TX
    looks like damn near a million. scat rods and resleeved.....whoa.

  4. Matts96HB

    Matts96HB . Moderator VIP

    Messages:
    6,483
    Likes Received:
    390
    Joined:
    Apr 16, 2006
    said somewhere that hes looking to make 500whp

    and this setup is definitely capable. nice build! :thumbsup:

  5. D16SiHatch

    D16SiHatch New Member

    Messages:
    1,297
    Likes Received:
    44
    Joined:
    Sep 7, 2007
    with a resleeve and those rods i was expecing a power goal closer to 1,000. what gives :p

  6. NWDRVRBWE

    NWDRVRBWE Hands Off my Balls

    Messages:
    447
    Likes Received:
    15
    Joined:
    Mar 26, 2008
    Location:
    kentucky
    Est. swap and parts price?

  7. droszyk

    droszyk New Member

    Messages:
    33
    Likes Received:
    1
    Joined:
    Mar 1, 2010
    Location:
    Chesapeake, VA
    nice, maybe ill get to this level someday. i just plan on doing an H22A4 swap, naturally aspirated, with a light weight flywheel though.

  8. 94H_Ex

    94H_Ex Under employed

    Messages:
    1,453
    Likes Received:
    33
    Joined:
    Jun 17, 2008
    Location:
    Florida
    I'm in for the subscribe.

    Can't wait to see more.

  9. serrilion

    serrilion In my own little world! VIP

    Messages:
    1,758
    Likes Received:
    42
    Joined:
    Aug 13, 2007
    Location:
    Vermont
    Come this weekend guys, the motor will be back from the shop... then the parts start to get installed :)..... The engine is cost me I 1,100 to have the sleaves put into the block. The Cam and Cam kit cost me almost 2,000. So i would say for the motor alone some were between 3-5,000 lol... More to come this weekend when we get the block back from the shop... hehe

  10. NWDRVRBWE

    NWDRVRBWE Hands Off my Balls

    Messages:
    447
    Likes Received:
    15
    Joined:
    Mar 26, 2008
    Location:
    kentucky
    awesome, im excited to see it all. GL

  11. eg6turboLs

    eg6turboLs New Member

    Messages:
    28
    Likes Received:
    0
    Joined:
    Apr 12, 2010
    That's a nice build rite there..u kno if I can sleeve my blokk later on after its been built with forged pistons nd rods, the qs is can I used da same pistons if I wanted to sleeve in the future ( money issue) lol..

  12. SlushboxTeggy

    SlushboxTeggy It's only stupid if it doesn't work VIP

    Messages:
    9,392
    Likes Received:
    245
    Joined:
    Sep 14, 2004
    Location:
    New Jersey
    As long as the pistons are in working order you will be able to reuse them. You'll just need new rings. Next time make your own thread.

    Sweet looking build serrilion.

  13. serrilion

    serrilion In my own little world! VIP

    Messages:
    1,758
    Likes Received:
    42
    Joined:
    Aug 13, 2007
    Location:
    Vermont
    Ya she hopefully we get it together this weekend... proably have her 1st start up on Wed :) least were hopping... I will deff post that along with pictures :)... then the turbo parts go on hehe thats a bit later tho

  14. Taco15

    Taco15 I wear stretchy pants VIP

    Messages:
    6,998
    Likes Received:
    203
    Joined:
    Jan 11, 2005
    Location:
    Tallahassee Fl
    ohh glad to see another build thread.

    it seems we are growing up and not really doing alot of these anymore.

    best of luck to you sir. cant wait to see this thing put together!

  15. serrilion

    serrilion In my own little world! VIP

    Messages:
    1,758
    Likes Received:
    42
    Joined:
    Aug 13, 2007
    Location:
    Vermont
    Damn been 6 months... Well guess that what happens when you are over seas. So im going home finaly. The motor finaly was sleaved and redone... We sent the head out to be checked for cracks in what not.. None. Finaly got all the parts in, as some had to be placed on back order... I have some pictures for all of u... im home next week and will start the putting together process haha... anyways enjoy about 6-8,000 worth of parts and fun hehe.. :)
    (Sleaved H22A1 and Looking Sexxy)
    [​IMG]
    (OLD Type S pistons, who woulda thought?)
    [​IMG]
    [​IMG]
    (The Shop... and No im putting motor together in my house lol no dust)
    [​IMG]
    ( A car robed of its life)
    [​IMG]
    (A Car starting a new life)
    [​IMG]
    ( USDM Heads...strange JDM Bottom USDM Top?)
    [​IMG]
    ( The Trans with some goodies soon to come)
    [​IMG]
    (Waste Gate, will work for my HP goals)
    [​IMG]
    ( Intake Mani with new fuel Rail)
    [​IMG]
    ( All the engine Parts and Nick Nac Crap, Turbo kit was hidding)
    [​IMG]
    (Best Gasket Set money can buy)
    [​IMG]
    (255LHP in tank Pump... 1000cc RC Fuel Injectors)
    [​IMG]
    ( The Rod of doom)
    [​IMG]
    ( Stage 3 Turbo Cams from BC)
    [​IMG]
    (Skunk 2 Agj Cam Gears)
    [​IMG]
    (Greedy Kevlar Timing belt w Instructions)
    [​IMG]
    [​IMG]
    [​IMG]

    Other parts soon to come in pictures... T3/ T4 40mm turbo with love Fab Mini Mani... HKS or RS BOV, and exauhst.... also have new rims Tenzo DC6 V1

    All i got for now next week maybe an N/A start up woot woot!
