Cluster Pinouts - Help! USDM Civic and JDM Del sol

Discussion in 'Civic and del Sol - EG and EK' started by enot767, Oct 28, 2009.

  1. enot767

    enot767 New Member

    Messages:
    15
    Likes Received:
    0
    Joined:
    Jul 29, 2007
    Location:
    Maryland
    Hey guys, iv been doing alot of researching and iv decided that the s2k cluster swap isnt for me. i decided to go with the JDM 1993-1997 Del Sol cluster! so im in need of pinouts so i can make a plug and play harness so i dont have to ruin my OEM cluster harness. thanks in advance!!


    btw, if your wondering about the fitment issue im going to buy one of the gauge pod cluster bezels as seen here -
    [​IMG]

    and here is the cluster ill be using
    [​IMG]


    heres a stocker JDM cluster
    [​IMG]

    i plan on putting in a oil pressure pod in place of this persons air/fuel, and in place of the stock clock that is in this spot.

    then im going to cut it, and shave it a little so it matches up with the del sol cluster.. im assuming this will work, i dont have any actual measurements on it, it just looks to fit.
    -however i do own a plastic welder so i can pretty much make my own bezel if i have to. :)

    also, if any of you have seen a write up somewhere of someone doing this itd be great if you could link it, for i have searched and came up with NOTHING.

    thanks again!

  2. enot767

    enot767 New Member

    Messages:
    15
    Likes Received:
    0
    Joined:
    Jul 29, 2007
    Location:
    Maryland
    top.

    i just need the pinouts for the JDM delsol cluster!

  3. enot767

    enot767 New Member

    Messages:
    15
    Likes Received:
    0
    Joined:
    Jul 29, 2007
    Location:
    Maryland
    turns out its not a jdm cluster. its the USDM delsol vtec cluster - the one with the bseries.

    if anyone with a delsol cluster could measure the total length, and the height in the center of the cluster, then a height for the lowest portion straight up to the top itd be great. im trying to get measurements for i go head and buy a cluster

  4. enot767

    enot767 New Member

    Messages:
    15
    Likes Received:
    0
    Joined:
    Jul 29, 2007
    Location:
    Maryland
    also. i post more on a different forum so if your interested in doing this follow me on this thread:
    Del Sol Cluster into a Ek

    newest update:

    i made a wiring schematic for delsol cluster harness to a civic 96-00 cluster harness

    [​IMG]

  5. enot767

    enot767 New Member

    Messages:
    15
    Likes Received:
    0
    Joined:
    Jul 29, 2007
    Location:
    Maryland
    i just need the measurements then ill buy everything!! please someone get me the measurements of the delsol cluster!!

  6. enot767

    enot767 New Member

    Messages:
    15
    Likes Received:
    0
    Joined:
    Jul 29, 2007
    Location:
    Maryland
  7. xeroxero

    xeroxero New Member

    Messages:
    37
    Likes Received:
    1
    Joined:
    Oct 21, 2009
    Location:
    Fayetteville Ga
    bump. can you post your pinout wiring pic. i have a bunch others i snagged from other places.

  8. enot767

    enot767 New Member

    Messages:
    15
    Likes Received:
    0
    Joined:
    Jul 29, 2007
    Location:
    Maryland
    sorry about that, it shows up for me but i forgot to upload it. here it is:

    [​IMG]

    and these are the measurements i need of the sol cluster:

    [​IMG]
    yellow
    brown
    pink
    red
    blue

  9. dc231581

    dc231581 New Member

    Messages:
    32
    Likes Received:
    0
    Joined:
    Dec 16, 2006
    Location:
    seattle
    nice, how about pinouts for an ef?

  10. enot767

    enot767 New Member

    Messages:
    15
    Likes Received:
    0
    Joined:
    Jul 29, 2007
    Location:
    Maryland
    nah, i dont have them. you would have to find the pinouts for the ef cluster and match them to my delsol one. if you want i can host a excel spread sheet for you.

  11. enot767

    enot767 New Member

    Messages:
    15
    Likes Received:
    0
    Joined:
    Jul 29, 2007
    Location:
    Maryland
    quoted from NN4S on honda-tech.com



  12. dc231581

    dc231581 New Member

    Messages:
    32
    Likes Received:
    0
    Joined:
    Dec 16, 2006
    Location:
    seattle
    i have a dohc vtec usdm cluster

  13. enot767

    enot767 New Member

    Messages:
    15
    Likes Received:
    0
    Joined:
    Jul 29, 2007
    Location:
    Maryland
  14. dc231581

    dc231581 New Member

    Messages:
    32
    Likes Received:
    0
    Joined:
    Dec 16, 2006
    Location:
    seattle
    i bought it for 100.00, but what i really want is an s2000 cluster or usdm typer r cluster
