Injectors part 2

We may earn a small commission from affiliate links and paid advertisements. Terms

austin20110

Active Member
Ok
so before eg put a stop to the fun in the first injector thread i had a question..


if there is no voltage restriction it will cause the injectors to work at 100% right..
When an injector works at 100% what closes it, I though that would fri them.

just trying to understand injectors a little bit better


TurboMirage

That’s how you get ants
VIP
got this from some credible ford source:

An injector cannot operate "over peak duty cycle". Duty cycle is just a ratio between time injector is closed and open. It cannot go over 100%...as it means that injector is constantly open.



so i guess it would just flow continuously then?


austin20110

Active Member
So the injectors are controlled by the ecu right?
And the can open like half way or a quater of the way, or are they always all the way open or all the way closed and the amout of fuel is controlled by maybe the fuel pressure regulator?


TurboMirage

That’s how you get ants
VIP
the FPR just controls the amount of fuel entering the rail, provided by the pump.. keeping a max fuel pressure depending on the vacuum supplied to it.


TurboMirage

That’s how you get ants
VIP
me versus OP of other thread.



TurboMirage

That’s how you get ants
VIP
yeah, looks like its either on or off. where duty cycle shows how fast they can go on and off.
